The Flextral FX-06 (FX-06) is a high-performance hydraulic hose designed for a range of demanding applications. This hose is built to meet or exceed the specifications of SAE 100R5 and D.O.T. FMVSS 106, ensuring it delivers reliable performance in various hydraulic systems. The FX-06 features an internal diameter of 5/16 inches and an outer diameter of 0.68 inches (17.10 mm), making it suitable for tight routing needs with a minimum bend radius of 4 inches (102 mm). Constructed with a seamless, black, oil and heat-resistant synthetic rubber tube, the FX-06 is reinforced with one braid of synthetic yarn and one braid of steel wire, offering robust strength and durability. Its cover consists of a black, impregnated textile braid that is oil and mildew resistant and approved by MSHA for quality assurance. The hose's capabilities include handling maximum working pressures up to 2250 psi and burst pressures up to 9000 psi, making it highly effective for high-temperature hydraulic applications involving diesel fuel and lubricating oils. It is available in lengths ranging from a minimum of 12 inches to a maximum of 1200 inches. Flextral's FX series hoses like the FX-06 are typically used in environments requiring high temperature tolerance, such as mobile machinery and industrial applications where temperature ranges can pose challenges. The FX-06 also meets the SAE J19421 USCG H standards, confirming its suitability for maritime applications where U.S. Coast Guard approval is necessary. This model's versatility in length and durability under varying temperatures makes it an essential component for systems requiring reliability under pressure.
The Flextral FX-06 (FX-06) is a high-performance hydraulic hose designed for a range of demanding applications. This hose is built to meet or exceed the specifications of SAE 100R5 and D.O.T. FMVSS 106, ensuring it delivers reliable performance in various hydraulic systems. The FX-06 features an internal diameter of 5/16 inches and an outer diameter of 0.68 inches (17.10 mm), making it suitable for tight routing needs with a minimum bend radius of 4 inches (102 mm). Constructed with a seamless, black, oil and heat-resistant synthetic rubber tube, the FX-06 is reinforced with one braid of synthetic yarn and one braid of steel wire, offering robust strength and durability. Its cover consists of a black, impregnated textile braid that is oil and mildew resistant and approved by MSHA for quality assurance. The hose's capabilities include handling maximum working pressures up to 2250 psi and burst pressures up to 9000 psi, making it highly effective for high-temperature hydraulic applications involving diesel fuel and lubricating oils. It is available in lengths ranging from a minimum of 12 inches to a maximum of 1200 inches. Flextral's FX series hoses like the FX-06 are typically used in environments requiring high temperature tolerance, such as mobile machinery and industrial applications where temperature ranges can pose challenges. The FX-06 also meets the SAE J19421 USCG H standards, confirming its suitability for maritime applications where U.S. Coast Guard approval is necessary. This model's versatility in length and durability under varying temperatures makes it an essential component for systems requiring reliability under pressure.
FX 100R5 Textile Cover
Meets or exceeds performance requirements of SAE 100R5 and D.O.T. FMVSS 106.
Tube: Seamless, black, oil, and heat resistant synthetic rubber
Reinforcement: One braid of synthetic yarn and one braid of steel wire
Cover: Black, impregnated textile braid, oil and mildew resistent, MSHA approved
Temperature: 3⁄16” - 11⁄8” reels, 13⁄8” and higher in coils
Packaging: Coils
Application: Used for high-temperature, hydraulic applications, diesel fuel and lubricating oils. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE | REUSABLE | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | COUPLINGS | |
| FX-06 | 5⁄16 | 0.68 | 17.10 | 2250 | 9000 | 4 | 102.00 | 0.22 | coupling_FX | coupling_reusable |
