The Flextral FH-24 (FH-24) is a robust hydraulic hose designed for high-temperature applications, specifically tailored to meet or exceed the performance requirements of SAE 100R5 and D.O.T. FMVSS 106 standards. This hose features a seamless, black, oil and heat-resistant synthetic rubber tube. It is reinforced with one braid of synthetic yarn and one braid of steel wire, ensuring durability and reliable performance under pressure. The cover of the FH-24 is a blue, impregnated textile braid that is both oil and mildew resistant and approved by MSHA. With an internal diameter of 1.375 inches and an outer diameter of 1.75 inches (44.40 mm), the FH-24 hose supports a maximum working pressure of 500 psi and a minimum burst pressure of 2000 psi. It can be flexibly used within a minimum bend radius of 10.5 inches (267 mm). The hose is available in lengths ranging from 12 inches to a substantial maximum of 1200 inches, catering to various installation needs. The temperature range supported by the FH-24 makes it versatile for different mediums: from -40°C to +150°C (-40°F to +302°F) for petroleum-based fluids; -40°C to +107°C (-40°F to +225°F) for water-oil emulsions or water-glycol solutions; and -40°C to +42°C (-40°F to +180°F) for phosphate ester fluids. This hose is commonly utilized in applications involving high-temperature hydraulic systems and lubricating oils, where maintaining system integrity at elevated temperatures is crucial. Additionally, the Flextral FH-24 hose meets SAE J1942/1 USCG H standards, making it suitable for marine applications where U.S. Coast Guard approval is required. Its design ensures reliability in both stationary setups and mobile machinery across various high-demand environments.
The Flextral FH-24 (FH-24) is a robust hydraulic hose designed for high-temperature applications, specifically tailored to meet or exceed the performance requirements of SAE 100R5 and D.O.T. FMVSS 106 standards. This hose features a seamless, black, oil and heat-resistant synthetic rubber tube. It is reinforced with one braid of synthetic yarn and one braid of steel wire, ensuring durability and reliable performance under pressure. The cover of the FH-24 is a blue, impregnated textile braid that is both oil and mildew resistant and approved by MSHA. With an internal diameter of 1.375 inches and an outer diameter of 1.75 inches (44.40 mm), the FH-24 hose supports a maximum working pressure of 500 psi and a minimum burst pressure of 2000 psi. It can be flexibly used within a minimum bend radius of 10.5 inches (267 mm). The hose is available in lengths ranging from 12 inches to a substantial maximum of 1200 inches, catering to various installation needs. The temperature range supported by the FH-24 makes it versatile for different mediums: from -40°C to +150°C (-40°F to +302°F) for petroleum-based fluids; -40°C to +107°C (-40°F to +225°F) for water-oil emulsions or water-glycol solutions; and -40°C to +42°C (-40°F to +180°F) for phosphate ester fluids. This hose is commonly utilized in applications involving high-temperature hydraulic systems and lubricating oils, where maintaining system integrity at elevated temperatures is crucial. Additionally, the Flextral FH-24 hose meets SAE J1942/1 USCG H standards, making it suitable for marine applications where U.S. Coast Guard approval is required. Its design ensures reliability in both stationary setups and mobile machinery across various high-demand environments.
FH 100R5 Textile Cover - High-Temp.
Meets or exceeds performance requirements of SAE 100R5 and D.O.T. FMVSS 106.
Tube: Seamless, black, oil and heat resistant synthetic rubber
Reinforcement: One braid of synthetic yarn and one braid of steel wire
Cover: Blue, impregnated textile braid, oil and mildew resistent, MSHA approved
Temperature: -40°C to +150°C (-40°F to +302°F) - petroleum bases fluids, -40°C to +107°C (-40°F to +225°F) - water/oil emulsions or water glycol solutions, -40°C to +42°C (-40°F to +180°F) - phospate ester fluids
Packaging: 3⁄16” - 11⁄8” reels, 13⁄8” and higher in coils
Application: Used for high-temperature, hydraulic applications, and lubricating oils. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE | REUSABLE | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | COUPLINGS | |
| FH-24 | 13⁄8 | 1.75 | 44.40 | 500 | 2000 | 10.5 | 267.00 | 0.73 | coupling_FH | coupling_reusable |
