The Flextral FH-04 (FH-04) is a high-performance hydraulic hose designed for a variety of high-temperature applications. With an internal diameter of 3/16 inches and a maximum length of 1200 inches, this hose is versatile for various hydraulic setups. Weighing only 0.15 pounds per foot, it features a seamless, black, oil and heat-resistant synthetic rubber tube. The reinforcement includes one braid of synthetic yarn and one braid of steel wire, ensuring durability and high strength. The outer diameter measures 0.52 inches (13.20 mm), and the hose can withstand a maximum working pressure of 3000 psi with a minimum burst pressure of 12000 psi. The minimum bend radius is an impressive 3 inches (76 mm), allowing for flexibility in tight spaces. Its cover is a blue, impregnated textile braid that is oil and mildew resistant and also approved by MSHA. This hose meets or exceeds the performance requirements of SAE 100R5 and D.O.T. FMVSS 106 standards, making it suitable for high-temperature hydraulic applications, lubricating oils, water-oil emulsions or water glycol solutions, and phosphate ester fluids in temperatures ranging from -40°C to +150°C (-40°F to +302°F) for petroleum-based fluids, up to +107°C (+225°F) for water-based fluids, and up to +42°C (+180°F) for phosphate ester fluids. Designed specifically with the F5R coupling series compatibility in mind, the Flextral FH-04 offers reliable connections ensuring safety and efficiency in its applications which include various hydraulic systems where high temperature is a factor. This model's robust build quality makes it ideal for challenging industrial environments requiring dependable hydraulic solutions.
The Flextral FH-04 (FH-04) is a high-performance hydraulic hose designed for a variety of high-temperature applications. With an internal diameter of 3/16 inches and a maximum length of 1200 inches, this hose is versatile for various hydraulic setups. Weighing only 0.15 pounds per foot, it features a seamless, black, oil and heat-resistant synthetic rubber tube. The reinforcement includes one braid of synthetic yarn and one braid of steel wire, ensuring durability and high strength. The outer diameter measures 0.52 inches (13.20 mm), and the hose can withstand a maximum working pressure of 3000 psi with a minimum burst pressure of 12000 psi. The minimum bend radius is an impressive 3 inches (76 mm), allowing for flexibility in tight spaces. Its cover is a blue, impregnated textile braid that is oil and mildew resistant and also approved by MSHA. This hose meets or exceeds the performance requirements of SAE 100R5 and D.O.T. FMVSS 106 standards, making it suitable for high-temperature hydraulic applications, lubricating oils, water-oil emulsions or water glycol solutions, and phosphate ester fluids in temperatures ranging from -40°C to +150°C (-40°F to +302°F) for petroleum-based fluids, up to +107°C (+225°F) for water-based fluids, and up to +42°C (+180°F) for phosphate ester fluids. Designed specifically with the F5R coupling series compatibility in mind, the Flextral FH-04 offers reliable connections ensuring safety and efficiency in its applications which include various hydraulic systems where high temperature is a factor. This model's robust build quality makes it ideal for challenging industrial environments requiring dependable hydraulic solutions.
FH 100R5 Textile Cover - High-Temp.
Meets or exceeds performance requirements of SAE 100R5 and D.O.T. FMVSS 106.
Tube: Seamless, black, oil and heat resistant synthetic rubber
Reinforcement: One braid of synthetic yarn and one braid of steel wire
Cover: Blue, impregnated textile braid, oil and mildew resistent, MSHA approved
Temperature: -40°C to +150°C (-40°F to +302°F) - petroleum bases fluids, -40°C to +107°C (-40°F to +225°F) - water/oil emulsions or water glycol solutions, -40°C to +42°C (-40°F to +180°F) - phospate ester fluids
Packaging: 3⁄16” - 11⁄8” reels, 13⁄8” and higher in coils
Application: Used for high-temperature, hydraulic applications, and lubricating oils. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE | REUSABLE | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | COUPLINGS | |
| FH-04 | 3⁄16 | 0.52 | 13.20 | 3000 | 12000 | 3 | 76.00 | 0.15 | coupling_FH | coupling_reusable |
