The Flextral AXT-12 (AXT-12) is a high-performance hydraulic hose designed for various fluid power applications. This hose is part of the AXT series and boasts an internal diameter of 3/4 inches, with a robust outer diameter of 1.09 inches (27.60 mm). It is engineered to handle a maximum working pressure of 3000 psi and a minimum burst pressure of 12000 psi, ensuring reliability and safety in high-pressure environments. The AXT-12 has a minimum bending radius of 4.7 inches (120 mm), which allows for flexibility and ease of installation in tight spaces. Constructed with a nitrile tube and reinforced by two braids of high-tensile steel wire, this hose is built to last. The cover is made from black, oil, abrasion, and weather-resistant synthetic rubber that is MSHA approved, making it suitable for harsh working conditions. It can operate effectively within a temperature range from -40°C to +100°C (-40°F to +212°F), with intermittent use up to 120°C (248°F). The AXT-12 is versatile in its applications; it can transport petroleum-based hydraulic fluids, gasoline, water, diesel fuels, lubricating oils, biodegradable hydraulic oil, as well as fire-resistant synthetic polyol esters. Its compliance with SAE J19421 USCG H standards further confirms its suitability for use in marine and offshore environments where US Coast Guard acceptance is required. Available in lengths ranging from 12 inches to 1200 inches and using the EN coupling series, the AXT-12 offers flexibility in usage across various systems requiring durable hydraulic hoses that meet stringent industry standards.
The Flextral AXT-12 (AXT-12) is a high-performance hydraulic hose designed for various fluid power applications. This hose is part of the AXT series and boasts an internal diameter of 3/4 inches, with a robust outer diameter of 1.09 inches (27.60 mm). It is engineered to handle a maximum working pressure of 3000 psi and a minimum burst pressure of 12000 psi, ensuring reliability and safety in high-pressure environments. The AXT-12 has a minimum bending radius of 4.7 inches (120 mm), which allows for flexibility and ease of installation in tight spaces. Constructed with a nitrile tube and reinforced by two braids of high-tensile steel wire, this hose is built to last. The cover is made from black, oil, abrasion, and weather-resistant synthetic rubber that is MSHA approved, making it suitable for harsh working conditions. It can operate effectively within a temperature range from -40°C to +100°C (-40°F to +212°F), with intermittent use up to 120°C (248°F). The AXT-12 is versatile in its applications; it can transport petroleum-based hydraulic fluids, gasoline, water, diesel fuels, lubricating oils, biodegradable hydraulic oil, as well as fire-resistant synthetic polyol esters. Its compliance with SAE J19421 USCG H standards further confirms its suitability for use in marine and offshore environments where US Coast Guard acceptance is required. Available in lengths ranging from 12 inches to 1200 inches and using the EN coupling series, the AXT-12 offers flexibility in usage across various systems requiring durable hydraulic hoses that meet stringent industry standards.
AXT 100R17 Leveline 3000 PSI
Meets or exceeds the requirements of SAE 100R17.
Tube: Nitrile
Reinforcement: Two braids of high-tensile steel wire
Cover: Black, oil, abrasion and weather resistant synthetic rubber, MSHA approved
Temperature: Temperature: -40°C to +100°C (-40°F to +212°F), intermittent use up to +120°C (+248°F)
Packaging: Reels
Application: Petroleum based hydraulic fluids, gasoline, water, diesel fuels and lubricating oils, biodegradeablehydraulic oil, fire resistant synthetic polyol esters, SAE J1942/1 USCG – H accepted. Petroleum based hydraulic fluids, gasoline, water, diesel fuels and lubricating oils, biodegradeable hydraulic oil, fire resistant synthetic polyol esters. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE | ||
|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | |
| AXT-12 | 3⁄4 | 1.09 | 27.60 | 3000 | 12000 | 4.7 | 120.00 | 0.51 | coupling_AXT |
