The Flextral AXT-06 (AXT-06) is a high-performance hydraulic hose designed for various fluid handling applications. This hose features an internal diameter of 3/8 inches and an outer diameter of 0.63 inches, with a length range from a minimum of 12 inches to a maximum of 1200 inches. It is constructed with two braids of high-tensile steel wire reinforcement and has a black, oil, abrasion, and weather-resistant synthetic rubber cover that is MSHA approved. The AXT-06 operates efficiently within a temperature range of -40°C to +100°C (-40°F to +212°F), with intermittent use up to 120°C (248°F). Its design meets or exceeds the requirements of SAE 100R17, ensuring reliable performance and durability. The hose's maximum working pressure is rated at 3000 psi, with a minimum burst pressure of 12000 psi, and it has a minimum bend radius of 65 mm (2.6 inches). Suitable for use with petroleum-based hydraulic fluids, gasoline, water, diesel fuels, lubricating oils, biodegradable hydraulic oil, and fire-resistant synthetic polyol esters. The Flextral AXT-06 also complies with SAE J19421 USCG H standards for marine applications. This versatility makes the AXT-06 ideal for demanding environments requiring stringent specifications and robust hose solutions.
The Flextral AXT-06 (AXT-06) is a high-performance hydraulic hose designed for various fluid handling applications. This hose features an internal diameter of 3/8 inches and an outer diameter of 0.63 inches, with a length range from a minimum of 12 inches to a maximum of 1200 inches. It is constructed with two braids of high-tensile steel wire reinforcement and has a black, oil, abrasion, and weather-resistant synthetic rubber cover that is MSHA approved. The AXT-06 operates efficiently within a temperature range of -40°C to +100°C (-40°F to +212°F), with intermittent use up to 120°C (248°F). Its design meets or exceeds the requirements of SAE 100R17, ensuring reliable performance and durability. The hose's maximum working pressure is rated at 3000 psi, with a minimum burst pressure of 12000 psi, and it has a minimum bend radius of 65 mm (2.6 inches). Suitable for use with petroleum-based hydraulic fluids, gasoline, water, diesel fuels, lubricating oils, biodegradable hydraulic oil, and fire-resistant synthetic polyol esters. The Flextral AXT-06 also complies with SAE J19421 USCG H standards for marine applications. This versatility makes the AXT-06 ideal for demanding environments requiring stringent specifications and robust hose solutions.
AXT 100R17 Leveline 3000 PSI
Meets or exceeds the requirements of SAE 100R17.
Tube: Nitrile
Reinforcement: Two braids of high-tensile steel wire
Cover: Black, oil, abrasion and weather resistant synthetic rubber, MSHA approved
Temperature: Temperature: -40°C to +100°C (-40°F to +212°F), intermittent use up to +120°C (+248°F)
Packaging: Reels
Application: Petroleum based hydraulic fluids, gasoline, water, diesel fuels and lubricating oils, biodegradeablehydraulic oil, fire resistant synthetic polyol esters, SAE J1942/1 USCG – H accepted. Petroleum based hydraulic fluids, gasoline, water, diesel fuels and lubricating oils, biodegradeable hydraulic oil, fire resistant synthetic polyol esters. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE | ||
|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | |
| AXT-06 | 3⁄8 | 0.63 | 16.00 | 3000 | 12000 | 2.6 | 65.00 | 0.18 | coupling_AXT |
