SUN HYDRAULICS
ZYS
- SUN HYDRAULICS
- Material:ZYS
- Summary:Manifold
Due to extremely high demand, please call 888-905-7411 for availability
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics ZYS (Material Number: ZYS) is a specialized gasket mount manifold designed for hydraulic systems. This component features a unique interface that facilitates port 1 to connect directly to the gasket port, while enabling fluid passage through ports 2 and 3. It is equipped with two mounting holes, each with a diameter of 0.41 inches (10.4 mm), designed for through-hole mounting, ensuring secure installation in hydraulic assemblies. The manifold accommodates one open cavity of type T-2A and utilizes SAE 6 port sizes, making it compatible with standard hydraulic fittings and connections. This manifold is particularly noteworthy for its construction materials and pressure ratings. Users must carefully consider the maximum system pressure when integrating this component into their systems. Manifolds made from aluminum are not suitable for applications involving pressures exceeding 3000 psi (210 bar), regardless of the specified port size or type. This limitation underscores the importance of selecting appropriate materials based on system requirements to ensure safety and performance. The Sun Hydraulics ZYS is ideal for applications requiring precise control and distribution of hydraulic fluids within a system, offering reliability and efficiency in operation. Its design supports various configurations in hydraulic circuits, making it versatile for different operational needs within its pressure limitations.
The Sun Hydraulics ZYS (Material Number: ZYS) is a specialized gasket mount manifold designed for hydraulic systems. This component features a unique interface that facilitates port 1 to connect directly to the gasket port, while enabling fluid passage through ports 2 and 3. It is equipped with two mounting holes, each with a diameter of 0.41 inches (10.4 mm), designed for through-hole mounting, ensuring secure installation in hydraulic assemblies. The manifold accommodates one open cavity of type T-2A and utilizes SAE 6 port sizes, making it compatible with standard hydraulic fittings and connections. This manifold is particularly noteworthy for its construction materials and pressure ratings. Users must carefully consider the maximum system pressure when integrating this component into their systems. Manifolds made from aluminum are not suitable for applications involving pressures exceeding 3000 psi (210 bar), regardless of the specified port size or type. This limitation underscores the importance of selecting appropriate materials based on system requirements to ensure safety and performance. The Sun Hydraulics ZYS is ideal for applications requiring precise control and distribution of hydraulic fluids within a system, offering reliability and efficiency in operation. Its design supports various configurations in hydraulic circuits, making it versatile for different operational needs within its pressure limitations.
| Body Type | Gasket mountGasket mount |
| Interface | SpecialSpecial |
| Body Features | Port 1 to gasket port, through ports 2 and 3Port 1 to gasket port, through ports 2 and 3 |
| Mounting Hole Diameter | .41 in.10,4 mm |
| Mounting Hole Depth | ThroughThrough |
| Mounting Hole Quantity | 22 |
| Open Cavities | 11 |
| Cavity | T-2A |
| Port Size | SAE 6SAE 6 |
Notes:
- Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
