SUN HYDRAULICS
CAVITY PLUG
XFOAXXV
$23.80
- SUN HYDRAULICS
- Material:XFOAXXV
- Model:XFOA-XXV
- Summary:Cartridge
Quantity in stock: 128
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics XFOAXXV (XFOAXXV) is a versatile cavity plug designed for use in both two-port and four-port cavities, ensuring that all ports remain connected. These plugs are particularly suitable for corrosive environments, thanks to their corrosion-resistant construction. The bodies of the plugs are crafted from high-strength lean duplex stainless steel, while the internal components are made from carbon steel leaded alloy, similar to standard plugs. This product is compatible with Cavity T10A, T13A, and T31A Series 1 configurations and can handle a maximum operating pressure of up to 5000 psi (350 bar). The valve hex size measures 7/8 inches (22.2 mm), and the recommended installation torque ranges between 30 to 35 lbf-ft (41 to 47 Nm). For sealing purposes, a Viton seal kit with the cartridge number 990010006 is available. This cavity plug offers reliable performance in demanding applications where maintaining port connections in harsh conditions is essential.
The Sun Hydraulics XFOAXXV (XFOAXXV) is a versatile cavity plug designed for use in both two-port and four-port cavities, ensuring that all ports remain connected. These plugs are particularly suitable for corrosive environments, thanks to their corrosion-resistant construction. The bodies of the plugs are crafted from high-strength lean duplex stainless steel, while the internal components are made from carbon steel leaded alloy, similar to standard plugs. This product is compatible with Cavity T10A, T13A, and T31A Series 1 configurations and can handle a maximum operating pressure of up to 5000 psi (350 bar). The valve hex size measures 7/8 inches (22.2 mm), and the recommended installation torque ranges between 30 to 35 lbf-ft (41 to 47 Nm). For sealing purposes, a Viton seal kit with the cartridge number 990010006 is available. This cavity plug offers reliable performance in demanding applications where maintaining port connections in harsh conditions is essential.
These cavity plugs can be used for both two-port and four-port cavities and allow all ports to remain connected.
- Corrosion resistant cavity plugs are intended for use in corrosive environments and are identified by the model code suffix /AP (see Option Selection below). The bodies of these plugs are made from high strength lean duplex stainless steel. Internal parts are made from carbon steel leaded alloy, the same as standard plugs.
| Cavity | T-10A, T-13A & T-31A |
| Series | 1 |
| Maximum Operating Pressure | 5000 psi350 bar |
| Port Configuration | 2 Port / 4 Port2 Port / 4 Port |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Seal kit - Cartridge | Viton: 990-010-006 |
