SUN HYDRAULICS
CAVITY PLUG
XBOAXXN
$28.40
- SUN HYDRAULICS
- Material:XBOAXXN
- Model:XBOA-XXN
- Summary:Cartridge
Quantity in stock: 22
This cavity plug allows ports 1 and 2 to remain open and blocks port 3.
- Corrosion resistant cavity plugs are intended for use in corrosive environments and are identified by the model code suffix /AP (see Option Selection below). The bodies of these plugs are made from high strength lean duplex stainless steel. Internal parts are made from carbon steel leaded alloy, the same as standard plugs.
| Cavity | T-2A |
| Series | 2 |
| Maximum Operating Pressure | 5000 psi350 bar |
| Port Configuration | 3 Port3 Port |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-202-006 |
