SUN HYDRAULICS
SHUTTLE CART
CSAXXXN


$24.20 USD
  • SUN HYDRAULICS
  • Material:CSAXXXN
  • Model:CSAX-XXN
  • Summary:Cartridge

Quantity in stock: 3

The single ball shuttle connects the higher of two work ports to the signal or common port. The signal is sensed at port 3.

  • Shuttle cartridges feature hardened steel balls and seats for excellent wear characteristics and contamination tolerance.
  • The single ball allows for the decay of the pressure signal when both load ports drop to a lower pressure.
  • Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.

Cavity T-163A
Series 0
Capacity 1.25 gpm4,7 L/min.
Maximum Operating Pressure 5000 psi350 bar
Maximum Valve Leakage at 110 SUS (24 cSt) 5 drops/min.0,3 cc/min.
Valve Hex Size 3/4 in.19,1 mm
Valve Installation Torque 20 - 25 lbf ft27 - 33 Nm
Model Weight .20 lb0,10 kg
Seal kit - Cartridge Viton: 990-163-006
