HYDRAFORCE
5028289

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5028289 (5028289) is a solenoid-operated, 4-port, 3-position, direct-acting spool type screw-in hydraulic cartridge valve designed for versatile application in hydraulic systems. This model features a unique configuration that allows it to effectively control the flow of hydraulic fluid in various operational states. When de-energized, the SV1047CX model blocks all ports to prevent any flow. Upon activation of coil 1, the valve permits flow from port 3 to port 4 and from port 2 to port 1, facilitating effective directional control in hydraulic circuits. When coil 2 is energized instead, the flow direction changes from port 3 to port 2 and from port 4 to port 1. This valve is particularly useful in applications where work port flows are unequal due to cylinder ratios; directing higher return flows to port 2 can optimize performance. Key features of this model include a continuous-duty rated solenoid and hardened precision spool and cage which enhance its durability and lifespan. The unit offers various customization options such as optional coil voltages and terminations, manual override capabilities, and waterproof E-Coils that are rated up to IP69K for superior resistance against dust and water ingress. Moreover, its efficient wet-armature construction ensures reliable operation while all ports can withstand full pressurization for robust performance in demanding environments. The cartridges of this model are voltage interchangeable which adds flexibility across different system requirements. Additionally, its unitized, molded coil design alongside an industry common cavity promotes ease of installation and maintenance. This combination of advanced features makes the Hydraforce 5028289 a highly adaptable solution suitable for a wide range of industrial hydraulic applications.
