HYDRAFORCE
5027777


$138.75 USD
  • HYDRAFORCE
  • Material:5027777
  • Model:SV10-44-8T-N-12ER SOLENOID VALVE
  • Summary:SOLENOID CARTRIDGE VALVE 2 POSITION, 4 WAY

Quantity in stock: 0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5027777 (5027777) is a high-performance hydraulic control valve designed for precise fluid handling in various applications. This direct-acting 2 position, 4-way directional control valve is engineered as a screw-in cartridge type, making it suitable for integration into complex hydraulic systems. It operates efficiently with general-purpose hydraulic fluids. Key features of the SV1044 model include a continuous-duty rated coil and a hardened precision spool and cage, which enhance its durability and extend its operational lifespan. The valve's efficient wet-armature construction ensures reliable performance under varying conditions. Moreover, the cartridges of this model are voltage interchangeable, which provides flexibility in terms of adjustments and replacements. All ports on the SV1044 can be fully pressurized, allowing for versatile application across different hydraulic tasks. The unitized, molded coil design contributes to its robustness, while the optional manual override increases its utility in manual control situations. For environments requiring rigorous standards, there are optional waterproof E-Coils available that are rated up to IP69K, ensuring protection against ingress of dust and high-temperature high-pressure water jets. Additionally, this model utilizes an industry-common cavity which simplifies installation and maintenance processes by making it compatible with standard cavities used in similar devices. Optional coil voltages and terminations allow customization based on specific system requirements or preferences. The Hydraforce 5027777 is thus an adaptable solution for directing flow in hydraulic systems across various sectors requiring precise fluid control.
RatingsFlow Ratings
Flow rating: 23 lpm (6 gpm)

Maximum internal leakage: 82 ml/min (5 in³/min)
Max at 207 bar (3000 psi)

Pressure Ratings
Pressure rating: 207 bar (3000 psi)

Temperature Ratings
Operating fluid temperature: -40 to 120 °C
With buna N seals
Electrical ParametersMinimum pull in voltage: 85% of nominal at 40 °C

Drop out voltage: 5% of nominal at
40 °C
Performancehttps://www.hydraforce.com/globalassets/product-images/sv10-44_perf_chrt2022-02-24.gif

Installation SpecificationsCavity:
10-size-4-way Cavities
Order CodePOSITION CODE DESCRIPTION SV10-44E-H-J-L E Manual Override E BLANK NONE E J Momentary Pull Override, #10-32 threads E M Two Position Override, Red Knurled Knob E Y Momentary Pull Override, Red Knurled Knob H Line Body H 0 No Body H 6T Aluminum SAE 6 H 8T Aluminum SAE 8 H 6TD Ductile Iron SAE 6 J Seal J N Buna-N J V Fluorocarbon J P Polyurethane J U PPDI Urethane L Coil L 0 No Coil L 10DG 10 VDC, D-Coil, DIN 43650 L 10DL 10 VDC, D-Coil, Dual Lead Wires L 10DR/D 10 VDC, D-Coil, Deutsch with Diode L 10DS 10 VDC, D-Coil, Dual Spade L 10EL 10 VDC, E-Coil, Dual Lead Wires L 10ER 10 VDC, E-Coil, Deutsch L 10ER/Z 10 VDC, E-Coil, Deutsch with Zener Diode L 12DG 12 VDC, D-Coil, DIN 43650 L 12DL 12 VDC, D-Coil, Dual Lead Wires, 18 inches long L 12DL/36 12 VDC, D-Coil, Dual Lead Wires, 36 inches long L 12DL/W 12 VDC, D-Coil, Dual Lead Wires with Weatherpak L 12DL/W/D 12 VDC, D-Coil, Dual Lead Wires with Weatherpak with Diode L 12DR 12 VDC, D-Coil, Deutsch L 12DR/D 12 VDC, D-Coil, Deutsch with Diode L 12DR/Z 12 VDC, D-Coil, Deutsch with Zener Diode L 12DS 12 VDC, D-Coil, Dual Spade L 12EG 12 VDC, E-Coil, DIN 43650 L 12EJ 12 VDC, E-Coil, AMP Jr. L 12EL 12 VDC, E-Coil, Dual Lead Wires, 18 inches long L 12EL/36 12 VDC, E-Coil, Dual Lead Wires, 36 inches long L 12EL/W/Z 12 VDC, E-Coil, Dual Lead Wires with WeatherPak and Zener Diode L 12EL/Z 12 VDC, E-Coil, Dual Lead Wires with Zener Diode L 12ER 12 VDC, E-Coil, Deutsch L 12ER/Z 12 VDC, E-Coil, Deutsch with Zener Diode L 12EY 12 VDC, E-Coil, Metri-Pack 150 L 12EY/Z 12 VDC, E-Coil, Metri-Pack 150 with Zener Diode L 20DR/D 20 VDC, D-Coil, Deutsch with Diode L 20DS 20 VDC, D-Coil, Dual Spade L 20ER 20 VDC, E-Coil, Deutsch L 24AG 24 VDC, D-Coil, DIN 43650 L 24AP 24 VDC, D-Coil, 1/2" Conduit and Dual Lead Wires L 24DG 24 VDC, D-Coil, DIN 43650 L 24DL 24 VDC, D-Coil, Dual Lead Wires L 24DL/W 24 VDC, D-Coil, Dual Lead Wires with Weatherpak L 24DL/W/D 24 VDC, D-Coil, Dual Lead Wires with Weatherpak with Diode L 24DP 24 VDC, D-Coil, 1/2" Conduit and Dual Lead Wires L 24DR 24 VDC, D-Coil, Deutsch L 24DR/D 24 VDC, D-Coil, Deutsch with Diode L 24DS 24 VDC, D-Coil, Dual Spade L 24EG 24 VDC, E-Coil, DIN 43650 L 24EJ 24 VDC, E-Coil, AMP Jr. L 24EL 24 VDC, E-Coil, Dual Lead Wires, 18 inches long L 24EL/36 24 VDC, E-Coil, Dual Lead Wires, 36 inches long L 24EL/W/Z 24 VDC, E-Coil, Dual Lead Wires with WeatherPak and Zener Diode L 24ER 24 VDC, E-Coil, Deutsch L 24ER/Z 24 VDC, E-Coil, Deutsch with Zener Diode L 24EY 24 VDC, E-Coil, Metri-Pack 150 L 24EY/Z 24 VDC, E-Coil, Metri-Pack 150 with Zener Diode L 36DS 36 VDC, D-Coil, Dual Spade L 115AG 115 VAC, D-Coil, DIN 43650 L 115AP 115 VAC, D-Coil, 1/2" Conduit and Dual Lead Wires L 230AG 230 VAC, D-Coil, DIN 43650 L 230AP 230 VAC, D-Coil, 1/2" Conduit and Dual Lead Wires
https://www.hydraforce.com/globalassets/product-images/sv10-44_dim_dwg2022-02-24.gif


Seal kit:
Seal kit installation instructions
Housings:
Available
10-4w valve bodies
Coils:
10 size D
coils
10 size E
coils
