HYDAC
3008939
$8.01
- HYDAC
- Material:3008939
- Model:HRL-7-DP-A4
- Summary:HRL 7 DP A4
Quantity in stock: 0
Clamps to DIN 3015 are a perfected modular system for the mounting of pipes with static and dynamic loads.
Advantages
- shock-absorbing, vibration-damping and noise-absorbing properties
- compensation of pipe allowances and axial divergences
- exclusion against corrosion by all around surface treatment
- economical stick in and screw assembly of the bayonet nut
- smooth component mounting by clamp body of thermoplastic rubber
- weld plates formed of one part
- steel parts with sufficient surface protection
- safe overhead mounting by fixing effect of the plastic parts
Part 1 Light range
- Diameter range from 6 - 54 mm
- with elastomer insert of 6 - 32 mm
Part 2 Heavy range
- Diameter range from 6 - 406.4 mm
- with elastomer insert of 6 - 140 mm
Part 3 Twin clamps
- Diameter range from 6 -42 mm
Materials
PA, PP, thermoplastic elastomer
