***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Flextral directly.***
The Flextral VT300-24 (VT300-24) is a high-performance hydraulic hose designed for demanding applications in hydraulic systems using petroleum, polyolester, or water-glycol based fluids. This model, part of the VT300 series, features an internal diameter of 1.5 inches and a robust construction with an outer diameter of 2.19 inches (55.60 mm). It is engineered to handle a maximum working pressure of 5000 psi and a minimum burst pressure of 20000 psi, ensuring safety and reliability under high-pressure conditions. The VT300-24 hose is built with six spirals of high-tensile steel wire reinforcement and a nitrile tube that exceeds the requirements of SAE 100R13 standards. Its cover is made from synthetic rubber which is not only highly abrasion-resistant but also meets MSHA fire-resistant standards, enhancing its durability and suitability for harsh environments. The flexibility of this hose is notable, with a minimum bending radius of 13 inches (330 mm), making it more adaptable than standard spiral hoses to various configurations. This product has been meticulously designed to withstand temperature ranges from -48°C to 121°C (-55°F to 250°F), accommodating extreme conditions in various hydraulic applications. Additionally, the VT300-24 comes in coils and can be ordered in lengths ranging from a minimum of 12 inches up to a maximum of 1200 inches, providing versatility for specific installation requirements. The coupling series recommended for this hose is the VS series, ensuring compatible and secure connections for optimal performance. Overall, the Flextral VT300-24 hydraulic hose stands out due to its superior strength, flexibility, and resistance properties, making it an ideal choice for high-pressure hydraulic applications requiring durability and reliability.
The Flextral VT300-24 (VT300-24) is a high-performance hydraulic hose designed for demanding applications in hydraulic systems using petroleum, polyolester, or water-glycol based fluids. This model, part of the VT300 series, features an internal diameter of 1.5 inches and a robust construction with an outer diameter of 2.19 inches (55.60 mm). It is engineered to handle a maximum working pressure of 5000 psi and a minimum burst pressure of 20000 psi, ensuring safety and reliability under high-pressure conditions. The VT300-24 hose is built with six spirals of high-tensile steel wire reinforcement and a nitrile tube that exceeds the requirements of SAE 100R13 standards. Its cover is made from synthetic rubber which is not only highly abrasion-resistant but also meets MSHA fire-resistant standards, enhancing its durability and suitability for harsh environments. The flexibility of this hose is notable, with a minimum bending radius of 13 inches (330 mm), making it more adaptable than standard spiral hoses to various configurations. This product has been meticulously designed to withstand temperature ranges from -48°C to 121°C (-55°F to 250°F), accommodating extreme conditions in various hydraulic applications. Additionally, the VT300-24 comes in coils and can be ordered in lengths ranging from a minimum of 12 inches up to a maximum of 1200 inches, providing versatility for specific installation requirements. The coupling series recommended for this hose is the VS series, ensuring compatible and secure connections for optimal performance. Overall, the Flextral VT300-24 hydraulic hose stands out due to its superior strength, flexibility, and resistance properties, making it an ideal choice for high-pressure hydraulic applications requiring durability and reliability.
VT300 Exceeds 100R13
Meets or exceeds the requirements of SAE 100R13.
Tube: Nitrile
Reinforcement: Six spirals of high-tensile steel wire
Cover: Synthetic rubber, high-abrasion resistant, meets requirements of MSHA fire resistant standards Temperature: -48°C to +121°C (-55°F to +250°F)
Temperature: -48°C to +121°C (-55°F to +250°F)
Packaging: Coils
Application: VT300 is ideal for hydraulic systems with petroleum, polyolester, or water/glycol based fluids. The hose is very flexible with a bending radius less than standard spiral hose and a high-abrasion resistant cover. Hose is accepted for hydraulic service. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE Skive | ||
|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | |
| VT300-24 | 11⁄2 | 2.19 | 55.60 | 5000 | 20000 | 13 | 330.00 | 3.20 | coupling_VT300 |
