FLEXTRAL
VF350-12
$26.00*Starting at $26.00 per foot
- FLEXTRAL
- Material:VF350-12
- Summary:VF350
Due to extremely high demand, please call 888-905-7411 for availability
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Flextral directly.***
The Flextral VF350-12 (VF350-12) is a robust hydraulic hose designed for systems that utilize petroleum or water-glycol based fluids, as well as for fuel and lubricating oils where high flexibility is essential. This model, part of the VF350 series, features an internal diameter of 1.34 inches and an outer diameter of 1.2 inches (30.50 mm). It can handle a maximum working pressure of 5000 psi and has a minimum burst pressure of 20000 psi, ensuring safe and efficient operation under demanding conditions. The hose is built with a seamless, black, oil and heat-resistant synthetic rubber tube, reinforced by four spirals of high-tensile wire (sizes 06 to 20) or six spirals (sizes 24 to 32), which provide exceptional strength and durability. The cover of the VF350-12 is crafted from black synthetic rubber that is resistant to oils, weather conditions, and high abrasion, making it suitable for harsh environments. This cover also meets MSHA standards for flame resistance. The hose's superior flexibility is supported by a minimum bend radius of only 4.75 inches (120 mm), facilitating ease of use in tight spaces and complex configurations. With temperature capabilities ranging from -40°C to +120°C (-40°F to +250°F), the VF350-12 ensures reliable performance across a wide range of temperatures. Each hose is available in lengths ranging from a minimum of 12 inches up to a maximum length of 1200 inches, packaged in coils for convenient handling and installation. Applications for this hose include hydraulic systems in various sectors where high-performance fluid transfer is required alongside supreme flexibility for ease of system integration and maintenance. It also meets SAE J1942/1 USCG H acceptance criteria for marine applications, further broadening its utility across different fields.
The Flextral VF350-12 (VF350-12) is a robust hydraulic hose designed for systems that utilize petroleum or water-glycol based fluids, as well as for fuel and lubricating oils where high flexibility is essential. This model, part of the VF350 series, features an internal diameter of 1.34 inches and an outer diameter of 1.2 inches (30.50 mm). It can handle a maximum working pressure of 5000 psi and has a minimum burst pressure of 20000 psi, ensuring safe and efficient operation under demanding conditions. The hose is built with a seamless, black, oil and heat-resistant synthetic rubber tube, reinforced by four spirals of high-tensile wire (sizes 06 to 20) or six spirals (sizes 24 to 32), which provide exceptional strength and durability. The cover of the VF350-12 is crafted from black synthetic rubber that is resistant to oils, weather conditions, and high abrasion, making it suitable for harsh environments. This cover also meets MSHA standards for flame resistance. The hose's superior flexibility is supported by a minimum bend radius of only 4.75 inches (120 mm), facilitating ease of use in tight spaces and complex configurations. With temperature capabilities ranging from -40°C to +120°C (-40°F to +250°F), the VF350-12 ensures reliable performance across a wide range of temperatures. Each hose is available in lengths ranging from a minimum of 12 inches up to a maximum length of 1200 inches, packaged in coils for convenient handling and installation. Applications for this hose include hydraulic systems in various sectors where high-performance fluid transfer is required alongside supreme flexibility for ease of system integration and maintenance. It also meets SAE J1942/1 USCG H acceptance criteria for marine applications, further broadening its utility across different fields.
VF350 Fury 5000
Meets or exceeds ISO 18752, MSHA Approved.
Tube: Seamless, black, oil, and heat resistant synthetic rubber
Reinforcement: Four spirals of high-tensile wire (-06 to -20), Six spirals of high-tensile wire (-24 to -32)
Cover: Black, oil, weather, and high-abrasion resistant synthetic rubber, MSHA approved
Temperature: -40ºC to +120ºC (-40ºF to +250ºF)
Packaging: Coils
Application: Hydraulic systems with petroleum or water/glycol based fluids and for fuel and lubricating oils where supreme flexibility is needed. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE Non-Skive | ONE PIECE Skive | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | COUPLINGS | |
| VF350-12 | 3⁄4 | 1.2 | 30.50 | 5000 | 20000 | 4.75 | 120.00 | 0.88 | N | |
