PX250 100R16 Compact Two Wire Braid Hose
Meets or exceeds the requirements of SAE 100R16 and EN857 2SC DIN 20022 2SN-ISO 1436 Type 2.
Tube: Nitrile
Reinforcement: Two braids of high-tensile steel wire
Cover: Black, oil, high-abrasion and weather resistant synthetic rubber, MSHA approved
Temperature: -40°C to +100°C (-40°F to +212°F) intermittent use up to +120°C (+248°F)
Packaging: ¼” - 1” Reels; 1¼” - 2” Coils
Application: Petroleum based hydraulic fluids, gasoline, water, diesel fuels and lubricating oils, biodegradeable hydraulic oil, fire resistant synthetic polyol esters. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE | ||
|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | |
| PX250-24 | 11⁄2 | 1.98 | 50.30 | 1450 | 6815 | 11.81 | 300.00 | 1.32 | coupling_PX250 |
