The Flextral PX250-10 (PX250-10) is a high-performance hydraulic hose designed for various fluid power transmission applications. This hose is part of the PX250 series and features a 5/8-inch internal diameter, with an external diameter of 23.80 mm or 0.94 inches. It is engineered to handle maximum working pressures up to 3625 psi and has a minimum burst pressure of 14500 psi, ensuring reliability and safety under tough conditions. Constructed with a nitrile tube and reinforced by two braids of high-tensile steel wire, the PX250-10 offers exceptional durability. The cover is made from a black, oil-resistant, high-abrasion, and weather-resistant synthetic rubber that is MSHA approved, providing additional protection against environmental elements and mechanical wear. The hose can operate in temperatures ranging from -40°C to +100°C (-40°F to +212°F), with intermittent service up to 120°C (248°F). With its compact design featuring a minimal bend radius of just 100 mm (3.9 inches), the PX250-10 provides superior flexibility for tight routing requirements in complex machinery setups. It is available in lengths from a minimum of 12 inches to a maximum of 1200 inches, accommodating various installation needs. This model is ideal for conveying petroleum-based hydraulic fluids, gasoline, water, diesel fuels, lubricating oils, biodegradable hydraulic oil, as well as fire-resistant synthetic polyol esters. It also meets or exceeds the requirements of SAE 100R16 and EN857 2SC DIN 20022 2SNISO 1436 Type 2 standards and holds SAE J19421 USCG H acceptance for marine applications.
The Flextral PX250-10 (PX250-10) is a high-performance hydraulic hose designed for various fluid power transmission applications. This hose is part of the PX250 series and features a 5/8-inch internal diameter, with an external diameter of 23.80 mm or 0.94 inches. It is engineered to handle maximum working pressures up to 3625 psi and has a minimum burst pressure of 14500 psi, ensuring reliability and safety under tough conditions. Constructed with a nitrile tube and reinforced by two braids of high-tensile steel wire, the PX250-10 offers exceptional durability. The cover is made from a black, oil-resistant, high-abrasion, and weather-resistant synthetic rubber that is MSHA approved, providing additional protection against environmental elements and mechanical wear. The hose can operate in temperatures ranging from -40°C to +100°C (-40°F to +212°F), with intermittent service up to 120°C (248°F). With its compact design featuring a minimal bend radius of just 100 mm (3.9 inches), the PX250-10 provides superior flexibility for tight routing requirements in complex machinery setups. It is available in lengths from a minimum of 12 inches to a maximum of 1200 inches, accommodating various installation needs. This model is ideal for conveying petroleum-based hydraulic fluids, gasoline, water, diesel fuels, lubricating oils, biodegradable hydraulic oil, as well as fire-resistant synthetic polyol esters. It also meets or exceeds the requirements of SAE 100R16 and EN857 2SC DIN 20022 2SNISO 1436 Type 2 standards and holds SAE J19421 USCG H acceptance for marine applications.
PX250 100R16 Compact Two Wire Braid Hose
Meets or exceeds the requirements of SAE 100R16 and EN857 2SC DIN 20022 2SN-ISO 1436 Type 2.
Tube: Nitrile
Reinforcement: Two braids of high-tensile steel wire
Cover: Black, oil, high-abrasion and weather resistant synthetic rubber, MSHA approved
Temperature: -40°C to +100°C (-40°F to +212°F) intermittent use up to +120°C (+248°F)
Packaging: ¼” - 1” Reels; 1¼” - 2” Coils
Application: Petroleum based hydraulic fluids, gasoline, water, diesel fuels and lubricating oils, biodegradeable hydraulic oil, fire resistant synthetic polyol esters. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE | ||
|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | |
| PX250-10 | 5⁄8 | 0.94 | 23.80 | 3625 | 14500 | 3.9 | 100.00 | 0.42 | coupling_PX250 |
