NT300 Exceeds 100R12
Meets or exceeds the requirements of SAE 100R12 / EN856, R9R/4SH.
Tube: Nitrile
Reinforcement: Four spirals of high-tensile steel wire
Cover: Synthetic rubber, high-abrasion resistant, meets requirements of MSHA fire resistance standards
Temperature: -54°C to +121°C (-65°F to +250°F)
Packaging: Coils
Application: NT300 is ideal for hydraulic systems with petroleum, polyol ester, or water/glycol based fluids The hose is very flexible with a bending radius less than standard spiral hose and a high-abrasion resistant cover. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE Non-Skive | ONE PIECE Skive | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | COUPLINGS | |
| NT300-32 | 2 | 2.6 | 68.00 | 3600 | 14400 | 19.7 | 500.00 | 2.97 | N | VS |
