***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Flextral directly.***
The Flextral NT300-16 (NT300-16) is a robust hydraulic hose designed for high-pressure applications. It exceeds the performance requirements of SAE 100R12 and EN856 standards, as well as R9R4SH specifications. Constructed with a nitrile tube and reinforced by four spirals of high-tensile steel wire, this hose ensures durability and excellent pressure handling capabilities, with a maximum working pressure of 5500 psi and a minimum burst pressure of 22000 psi. This model features an outer diameter of 1.44 inches (36.60 mm) and an internal diameter of 1 inch, making it suitable for a variety of hydraulic systems. The NT300-16 offers exceptional flexibility with a minimum bend radius of just 8.7 inches (220 mm), which is less than typical for standard spiral hoses, facilitating easier installation and use in tight spaces. The synthetic rubber cover provides high abrasion resistance and meets MSHA fire resistance standards, enhancing the hose's suitability for harsh environments. Additionally, it can handle temperature ranges from -54°C to +121°C (-65°F to +250°F), making it versatile for different operating climates. Designed specifically for systems using petroleum, polyol ester, or water-glycol based fluids, the NT300-16 also meets SAE J1942/1 USCG H standards. Its packaging in coils allows for efficient storage and handling. The coupling series NV further ensures compatibility with various fittings, emphasizing its adaptability across numerous hydraulic applications without the need for skiving.
The Flextral NT300-16 (NT300-16) is a robust hydraulic hose designed for high-pressure applications. It exceeds the performance requirements of SAE 100R12 and EN856 standards, as well as R9R4SH specifications. Constructed with a nitrile tube and reinforced by four spirals of high-tensile steel wire, this hose ensures durability and excellent pressure handling capabilities, with a maximum working pressure of 5500 psi and a minimum burst pressure of 22000 psi. This model features an outer diameter of 1.44 inches (36.60 mm) and an internal diameter of 1 inch, making it suitable for a variety of hydraulic systems. The NT300-16 offers exceptional flexibility with a minimum bend radius of just 8.7 inches (220 mm), which is less than typical for standard spiral hoses, facilitating easier installation and use in tight spaces. The synthetic rubber cover provides high abrasion resistance and meets MSHA fire resistance standards, enhancing the hose's suitability for harsh environments. Additionally, it can handle temperature ranges from -54°C to +121°C (-65°F to +250°F), making it versatile for different operating climates. Designed specifically for systems using petroleum, polyol ester, or water-glycol based fluids, the NT300-16 also meets SAE J1942/1 USCG H standards. Its packaging in coils allows for efficient storage and handling. The coupling series NV further ensures compatibility with various fittings, emphasizing its adaptability across numerous hydraulic applications without the need for skiving.
NT300 Exceeds 100R12
Meets or exceeds the requirements of SAE 100R12 / EN856, R9R/4SH.
Tube: Nitrile
Reinforcement: Four spirals of high-tensile steel wire
Cover: Synthetic rubber, high-abrasion resistant, meets requirements of MSHA fire resistance standards
Temperature: -54°C to +121°C (-65°F to +250°F)
Packaging: Coils
Application: NT300 is ideal for hydraulic systems with petroleum, polyol ester, or water/glycol based fluids The hose is very flexible with a bending radius less than standard spiral hose and a high-abrasion resistant cover. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE Non-Skive | ONE PIECE Skive | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | COUPLINGS | |
| NT300-16 | 1 | 1.44 | 36.60 | 5500 | 22000 | 8.7 | 220.00 | 1.25 | N|V | |
