The Flextral NT300-06 (NT300-06) is a robust hydraulic hose designed for high-pressure applications. This hose features a nitrile tube and four spirals of high-tensile steel wire reinforcement, ensuring superior strength and durability. The outer cover is made from synthetic rubber which is not only highly abrasion-resistant but also meets the MSHA fire resistance standards, enhancing the safety of the product under extreme conditions. With an internal diameter of 0.38 inches and an outer diameter of 20.30 mm, the NT300-06 can handle a maximum working pressure of 6000 psi and a minimum burst pressure of 24000 psi. It is particularly noted for its flexibility, offering a minimum bend radius of 125 mm, which is less than that typically required for standard spiral hoses. This makes it an excellent choice for installations in tight spaces and for systems that require frequent bending of the hose. The NT300-06 operates efficiently within a temperature range from -54°C to +121°C (-65°F to +250°F), making it suitable for various operating environments. This model uses N series couplings and comes in lengths ranging from a minimum of 12 inches to a maximum of 1200 inches. Ideal for hydraulic systems using petroleum, polyol ester, or water-glycol based fluids, the Flextral NT300-06 offers exceptional performance in terms of both flexibility and durability. Its design exceeds the requirements of SAE 100R12 EN856, R9R4SH standards and is also accepted under SAE J1942/1 USCG H specifications. Whether used in industrial machinery or mobile hydraulics, this hose provides reliable operation and long service life under challenging conditions.
The Flextral NT300-06 (NT300-06) is a robust hydraulic hose designed for high-pressure applications. This hose features a nitrile tube and four spirals of high-tensile steel wire reinforcement, ensuring superior strength and durability. The outer cover is made from synthetic rubber which is not only highly abrasion-resistant but also meets the MSHA fire resistance standards, enhancing the safety of the product under extreme conditions. With an internal diameter of 0.38 inches and an outer diameter of 20.30 mm, the NT300-06 can handle a maximum working pressure of 6000 psi and a minimum burst pressure of 24000 psi. It is particularly noted for its flexibility, offering a minimum bend radius of 125 mm, which is less than that typically required for standard spiral hoses. This makes it an excellent choice for installations in tight spaces and for systems that require frequent bending of the hose. The NT300-06 operates efficiently within a temperature range from -54°C to +121°C (-65°F to +250°F), making it suitable for various operating environments. This model uses N series couplings and comes in lengths ranging from a minimum of 12 inches to a maximum of 1200 inches. Ideal for hydraulic systems using petroleum, polyol ester, or water-glycol based fluids, the Flextral NT300-06 offers exceptional performance in terms of both flexibility and durability. Its design exceeds the requirements of SAE 100R12 EN856, R9R4SH standards and is also accepted under SAE J1942/1 USCG H specifications. Whether used in industrial machinery or mobile hydraulics, this hose provides reliable operation and long service life under challenging conditions.
NT300 Exceeds 100R12
Meets or exceeds the requirements of SAE 100R12 / EN856, R9R/4SH.
Tube: Nitrile
Reinforcement: Four spirals of high-tensile steel wire
Cover: Synthetic rubber, high-abrasion resistant, meets requirements of MSHA fire resistance standards
Temperature: -54°C to +121°C (-65°F to +250°F)
Packaging: Coils
Application: NT300 is ideal for hydraulic systems with petroleum, polyol ester, or water/glycol based fluids The hose is very flexible with a bending radius less than standard spiral hose and a high-abrasion resistant cover. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE Non-Skive | ONE PIECE Skive | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | COUPLINGS | |
| NT300-06 | 3⁄8 | 0.8 | 20.30 | 6000 | 24000 | 4.9 | 125.00 | 0.42 | N | |
