FLEXTRAL
LX-04

$14.14*Starting at $14.14 per foot
  • FLEXTRAL
  • Material:LX-04
  • Summary:LX

Due to extremely high demand, please call 888-905-7411 for availability

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Flextral directly.***
The Flextral LX-04 (LX-04) is a high-performance hydraulic hose designed for a wide range of applications requiring medium pressure. The LX series hose features a robust construction with an internal diameter of 14 inches and an outer diameter of 0.56 inches (14.30 mm). It has been engineered to handle maximum working pressures up to 1250 psi, with a minimum burst pressure of 5000 psi, ensuring reliability and safety in demanding environments. This model is notable for its flexibility, demonstrated by its minimum bend radius of just 3 inches (76 mm), making it suitable for tight configurations where space is limited. The hose’s length can vary from a minimum of 12 inches to a maximum of 1200 inches, accommodating various installation needs. Constructed from black, oil and heat-resistant synthetic rubber, the LX-04 also includes two braids of synthetic yarn reinforcement. This composition enhances the hose's durability and performance under extreme conditions. Its cover is crafted from black, oil abrasion, and weather-resistant synthetic rubber which provides additional protection against environmental elements and rough operating conditions. The LX-04 is primarily used for conveying petroleum-based hydraulic fluids and serves well in pneumatic services. Its temperature range extends from -40°C to +100°C (-40°F to +212°F), ensuring effective operation across a broad spectrum of temperatures commonly encountered in industrial applications. This product meets or exceeds the requirements of SAE 100R3, affirming its quality and compliance with industry standards.

LX 100R3 Rubber Cover Fabric Braid

Meets or exceeds the requirements of SAE 100R3.

Tube: Black, oil and heat-resistant synthetic rubber
Reinforcement: Two braids of synthetic yarn
Cover: Black, oil abrasion and weather resistant synthetic rubber
Temperature: -40°C to +100°C (-40°F to +212°F)
Packaging: Reels
Application: Petroleum based hydraulic fluids and pneumatic service.

PART NUMBER HOSE I.D. HOSE O.D. MAX W.P. MIN. BURST PRESSURE MIN. BEND RADIUS WEIGHT ONE PIECE
(in) (in) (mm) (psi) (psi) (in) (mm) (lbs/ft) COUPLINGS
LX-04140.5614.3012505000376.000.12coupling_LX
