HH 100R4 High-Temp. Suction / Return Hose
Meets or exceeds the requirements of SAE 100R4.
Tube: Seamless, black, oil and heat resistant synthetic rubber
Reinforcement: Two textile braids with spiral wire to prevent collapsing
Cover: Black, synthetic oil, and heat resistant rubber, MSHA approved
Temperature: -30°C to +135°C (-22°F to +275°F)
Packaging: 100’ Coils
Application: Petroleum and water base hydraulic fluids in suction lines or in low pressure return lines.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | VACUUM HG | ONE PIECE | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | (in) | COUPLINGS | |
| HH-64 | 4 | 4.73 | 120.00 | 200 | 800 | 12.6 | 320.00 | 3.23 | 28 | coupling_HH |
