The Flextral HH-48 (HH-48) is a high-performance hydraulic hose designed for suction and low-pressure return lines in hydraulic systems. It is part of the HH series, with an internal diameter of 3 inches and an outer diameter of 3.62 inches (92.00 mm). This hose can handle maximum working pressures up to 200 psi and has a minimum burst pressure rating of 800 psi. The minimum bend radius for this hose is 9.5 inches (240 mm), ensuring flexibility in tight spaces. Constructed from seamless, black, oil, and heat-resistant synthetic rubber, the HH-48 features two textile braids reinforced with a spiral wire to prevent collapsing under vacuum conditions, supporting a vacuum rating of 28 inches Hg. Its cover is also made from black synthetic rubber that is resistant to oil and heat, and it is MSHA approved for safety standards. The temperature range for this hose spans from -22°F to 275°F (-30°C to 135°C), making it suitable for environments requiring resistance to high temperatures. The Flextral HH-48 comes in lengths ranging from a minimum of 12 inches up to a maximum of 1200 inches and typically packaged in coils of 100 feet. This hose is primarily used for conveying petroleum and water-based hydraulic fluids, making it an essential component for sectors utilizing hydraulic machinery where high temperature and flexibility are critical factors. Its robust construction ensures durability and reliability in demanding applications.
The Flextral HH-48 (HH-48) is a high-performance hydraulic hose designed for suction and low-pressure return lines in hydraulic systems. It is part of the HH series, with an internal diameter of 3 inches and an outer diameter of 3.62 inches (92.00 mm). This hose can handle maximum working pressures up to 200 psi and has a minimum burst pressure rating of 800 psi. The minimum bend radius for this hose is 9.5 inches (240 mm), ensuring flexibility in tight spaces. Constructed from seamless, black, oil, and heat-resistant synthetic rubber, the HH-48 features two textile braids reinforced with a spiral wire to prevent collapsing under vacuum conditions, supporting a vacuum rating of 28 inches Hg. Its cover is also made from black synthetic rubber that is resistant to oil and heat, and it is MSHA approved for safety standards. The temperature range for this hose spans from -22°F to 275°F (-30°C to 135°C), making it suitable for environments requiring resistance to high temperatures. The Flextral HH-48 comes in lengths ranging from a minimum of 12 inches up to a maximum of 1200 inches and typically packaged in coils of 100 feet. This hose is primarily used for conveying petroleum and water-based hydraulic fluids, making it an essential component for sectors utilizing hydraulic machinery where high temperature and flexibility are critical factors. Its robust construction ensures durability and reliability in demanding applications.
HH 100R4 High-Temp. Suction / Return Hose
Meets or exceeds the requirements of SAE 100R4.
Tube: Seamless, black, oil and heat resistant synthetic rubber
Reinforcement: Two textile braids with spiral wire to prevent collapsing
Cover: Black, synthetic oil, and heat resistant rubber, MSHA approved
Temperature: -30°C to +135°C (-22°F to +275°F)
Packaging: 100’ Coils
Application: Petroleum and water base hydraulic fluids in suction lines or in low pressure return lines.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | VACUUM HG | ONE PIECE | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | (in) | COUPLINGS | |
| HH-48 | 3 | 3.62 | 92.00 | 200 | 800 | 9.5 | 240.00 | 2.21 | 28 | coupling_HH |
