The Flextral HH-40 (HH-40) is a high-quality hydraulic hose designed for both suction and low-pressure return lines. This model, part of the HH series, is specifically crafted to handle petroleum and water-based hydraulic fluids effectively. The hose boasts an internal diameter of 2.5 inches and an external diameter of 3.13 inches (79.50 mm), ensuring a robust structure that can sustain a maximum working pressure of 200 psi and a minimum burst pressure of 800 psi. Constructed with seamless, black, oil and heat-resistant synthetic rubber, the HH-40 ensures durability and reliable performance under various conditions. Its reinforcement includes two textile braids along with a spiral wire to prevent collapsing, making it suitable for demanding applications where maintaining hose shape and flow is critical. The cover of the hose is also made from black synthetic rubber that is resistant to oil and heat, and it has MSHA approval for quality assurance. With a minimum bend radius of 7.9 inches (200 mm) and a vacuum rating of 28 inHg, this hose offers flexibility and adaptability in installation across different systems. The temperature range from -22°F to +275°F (-30°C to +135°C) allows the HH-40 to perform efficiently in diverse environmental conditions. Available in lengths ranging from 12 inches to a maximum of 1200 inches, coupled with HA series fittings, this hose can be tailored to meet specific requirements while ensuring safety and efficiency in hydraulic operations.
The Flextral HH-40 (HH-40) is a high-quality hydraulic hose designed for both suction and low-pressure return lines. This model, part of the HH series, is specifically crafted to handle petroleum and water-based hydraulic fluids effectively. The hose boasts an internal diameter of 2.5 inches and an external diameter of 3.13 inches (79.50 mm), ensuring a robust structure that can sustain a maximum working pressure of 200 psi and a minimum burst pressure of 800 psi. Constructed with seamless, black, oil and heat-resistant synthetic rubber, the HH-40 ensures durability and reliable performance under various conditions. Its reinforcement includes two textile braids along with a spiral wire to prevent collapsing, making it suitable for demanding applications where maintaining hose shape and flow is critical. The cover of the hose is also made from black synthetic rubber that is resistant to oil and heat, and it has MSHA approval for quality assurance. With a minimum bend radius of 7.9 inches (200 mm) and a vacuum rating of 28 inHg, this hose offers flexibility and adaptability in installation across different systems. The temperature range from -22°F to +275°F (-30°C to +135°C) allows the HH-40 to perform efficiently in diverse environmental conditions. Available in lengths ranging from 12 inches to a maximum of 1200 inches, coupled with HA series fittings, this hose can be tailored to meet specific requirements while ensuring safety and efficiency in hydraulic operations.
HH 100R4 High-Temp. Suction / Return Hose
Meets or exceeds the requirements of SAE 100R4.
Tube: Seamless, black, oil and heat resistant synthetic rubber
Reinforcement: Two textile braids with spiral wire to prevent collapsing
Cover: Black, synthetic oil, and heat resistant rubber, MSHA approved
Temperature: -30°C to +135°C (-22°F to +275°F)
Packaging: 100’ Coils
Application: Petroleum and water base hydraulic fluids in suction lines or in low pressure return lines.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | VACUUM HG | ONE PIECE | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | (in) | COUPLINGS | |
| HH-40 | 21⁄2 | 3.13 | 79.50 | 200 | 800 | 7.9 | 200.00 | 1.82 | 28 | coupling_HH |
