The Flextral HH-24 (HH-24) is a high-performance hydraulic hose designed for robust applications requiring suction and low-pressure return lines. This hose is engineered to meet or exceed the requirements of SAE 100R4, ensuring top-tier performance and reliability. The HH-24 features an internal diameter of 1.5 inches and an outer diameter of 50.00 mm, making it suitable for a range of hydraulic systems. Constructed with a seamless, black, oil and heat-resistant synthetic rubber tube, the HH-24 is built to handle petroleum and water-based hydraulic fluids effectively. Its reinforcement includes two textile braids coupled with a spiral wire designed to prevent collapsing under suction, enhancing its durability and function in challenging environments. The cover of the hose is also crafted from black synthetic rubber that is both oil and heat resistant and comes MSHA approved. The HH-24 supports a maximum working pressure of 150 psi and can withstand burst pressures up to 600 psi. It has a minimum bending radius of 125 mm, which allows for flexibility in installation and use without compromising its structural integrity. Additionally, this model can operate within a temperature range from -22°F to 275°F (-30°C to 135°C), accommodating varying climatic conditions. This hose's design includes lengths ranging from a minimum of 12 inches up to a maximum length of 1200 inches, catering to extensive application needs across different setups. It also features compatibility with NHA series couplings, further extending its usability across various hydraulic systems requiring reliable fluid transport under medium pressure conditions.
The Flextral HH-24 (HH-24) is a high-performance hydraulic hose designed for robust applications requiring suction and low-pressure return lines. This hose is engineered to meet or exceed the requirements of SAE 100R4, ensuring top-tier performance and reliability. The HH-24 features an internal diameter of 1.5 inches and an outer diameter of 50.00 mm, making it suitable for a range of hydraulic systems. Constructed with a seamless, black, oil and heat-resistant synthetic rubber tube, the HH-24 is built to handle petroleum and water-based hydraulic fluids effectively. Its reinforcement includes two textile braids coupled with a spiral wire designed to prevent collapsing under suction, enhancing its durability and function in challenging environments. The cover of the hose is also crafted from black synthetic rubber that is both oil and heat resistant and comes MSHA approved. The HH-24 supports a maximum working pressure of 150 psi and can withstand burst pressures up to 600 psi. It has a minimum bending radius of 125 mm, which allows for flexibility in installation and use without compromising its structural integrity. Additionally, this model can operate within a temperature range from -22°F to 275°F (-30°C to 135°C), accommodating varying climatic conditions. This hose's design includes lengths ranging from a minimum of 12 inches up to a maximum length of 1200 inches, catering to extensive application needs across different setups. It also features compatibility with NHA series couplings, further extending its usability across various hydraulic systems requiring reliable fluid transport under medium pressure conditions.
HH 100R4 High-Temp. Suction / Return Hose
Meets or exceeds the requirements of SAE 100R4.
Tube: Seamless, black, oil and heat resistant synthetic rubber
Reinforcement: Two textile braids with spiral wire to prevent collapsing
Cover: Black, synthetic oil, and heat resistant rubber, MSHA approved
Temperature: -30°C to +135°C (-22°F to +275°F)
Packaging: 100’ Coils
Application: Petroleum and water base hydraulic fluids in suction lines or in low pressure return lines.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | VACUUM HG | ONE PIECE | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | (in) | COUPLINGS | |
| HH-24 | 11⁄2 | 1.97 | 50.00 | 150 | 600 | 4.9 | 125.00 | 0.90 | 28 | coupling_HH |
