The Flextral HF-20 (HF-20) is a robust hydraulic hose designed for versatile applications in suction and low-pressure return lines. This model, part of the HF series, features a 1.25-inch internal diameter and an outer diameter of 1.65 inches or 42.00 mm, ensuring a snug fit with compatible couplings from the EN series. Weighing only 0.60 lbs per foot, it offers a balance between durability and ease of handling. Constructed to meet or exceed the requirements of SAE 100R4, the HF-20 hose is built with a seamless, black oil and heat-resistant synthetic rubber tube. Its reinforcement includes textile braiding coupled with spiral wire to prevent collapsing under vacuum conditions, which can reach up to 28 inches of mercury (Hg). The cover of this hose is also made from black synthetic rubber that is resistant to both oil and heat and comes MSHA approved for added safety. The HF-20 can handle maximum working pressures up to 200 psi and can withstand burst pressures up to 800 psi. Its flexibility is highlighted by its minimum bend radius of just 2.4 inches or 60 mm, allowing for installation in tight spaces without kinking. The temperature range this hose can operate in spans from -40°C to +100°C (-40°F to +212°F), making it suitable for various environmental conditions. This hose is typically used for conveying petroleum and water-based hydraulic fluids, making it an ideal choice for industries requiring reliable fluid transfer solutions in both mobile equipment and stationary systems alike. It comes packaged in lengths up to 1200 feet but can be obtained in minimum lengths of just 12 inches, providing flexibility in usage according to specific project requirements.
The Flextral HF-20 (HF-20) is a robust hydraulic hose designed for versatile applications in suction and low-pressure return lines. This model, part of the HF series, features a 1.25-inch internal diameter and an outer diameter of 1.65 inches or 42.00 mm, ensuring a snug fit with compatible couplings from the EN series. Weighing only 0.60 lbs per foot, it offers a balance between durability and ease of handling. Constructed to meet or exceed the requirements of SAE 100R4, the HF-20 hose is built with a seamless, black oil and heat-resistant synthetic rubber tube. Its reinforcement includes textile braiding coupled with spiral wire to prevent collapsing under vacuum conditions, which can reach up to 28 inches of mercury (Hg). The cover of this hose is also made from black synthetic rubber that is resistant to both oil and heat and comes MSHA approved for added safety. The HF-20 can handle maximum working pressures up to 200 psi and can withstand burst pressures up to 800 psi. Its flexibility is highlighted by its minimum bend radius of just 2.4 inches or 60 mm, allowing for installation in tight spaces without kinking. The temperature range this hose can operate in spans from -40°C to +100°C (-40°F to +212°F), making it suitable for various environmental conditions. This hose is typically used for conveying petroleum and water-based hydraulic fluids, making it an ideal choice for industries requiring reliable fluid transfer solutions in both mobile equipment and stationary systems alike. It comes packaged in lengths up to 1200 feet but can be obtained in minimum lengths of just 12 inches, providing flexibility in usage according to specific project requirements.
HF 100R4 Suction / Return Hose
Meets or exceeds the requirements of SAE 100R4.
Tube: Seamless, black, oil and heat resistant synthetic rubber
Reinforcement: Textile braided with spiral wire to prevent collapsing
Cover: Black synthetic oil and heat-resistant rubber, MSHA approved
Temperature: -40°C to 100° (-40°F to +212°F)
Packaging: 100’ Coils
Application: Petroleum and water based hydraulic fluids in suction lines or in low pressure return lines.
PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | VACUUM HG | ONE PIECE | ||
---|---|---|---|---|---|---|---|---|---|---|
(in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | (in) | COUPLINGS | |
HF-20 | 11⁄4 | 1.65 | 42.00 | 200 | 800 | 2.4 | 60.00 | 0.60 | 28 | coupling_HF |
