The Flextral HF-16 (HF-16) is a robust hydraulic hose designed for flexibility and durability in managing petroleum and water-based hydraulic fluids. This model, part of the HF series, features an internal diameter of 1 inch and an external diameter of 1.38 inches, or 35.00 mm, ensuring a tight fit and strong flow capacity. It can handle a maximum working pressure of 250 psi and a minimum burst pressure of 1000 psi, making it capable of withstanding rigorous operational conditions. The HF-16's minimum bend radius is remarkably small at only 1.8 inches (45.00 mm), providing exceptional flexibility for tight configurations in machinery. Constructed from seamless, black oil- and heat-resistant synthetic rubber, the HF-16’s tube is designed to ensure safe and efficient fluid transport under various thermal conditions, ranging from -40°C to +100°C (-40°F to +212°F). The hose's reinforcement includes textile braiding with spiral wire to prevent collapsing under vacuum or during use, enhancing its structural integrity. Furthermore, its cover is made from black synthetic rubber that is also oil- and heat-resistant and approved by MSHA for quality assurance. Weighing only 0.50 lbs per foot and available in lengths ranging from a minimum of 12 inches to a maximum of 1200 inches, the HF-16 offers considerable versatility in installation options. It utilizes EN series couplings for secure connections, ensuring reliable integration into existing hydraulic systems. This model's design meets or exceeds the rigorous requirements set by SAE 100R4 standards, affirming its suitability for suction lines or low-pressure return lines in hydraulic applications.
The Flextral HF-16 (HF-16) is a robust hydraulic hose designed for flexibility and durability in managing petroleum and water-based hydraulic fluids. This model, part of the HF series, features an internal diameter of 1 inch and an external diameter of 1.38 inches, or 35.00 mm, ensuring a tight fit and strong flow capacity. It can handle a maximum working pressure of 250 psi and a minimum burst pressure of 1000 psi, making it capable of withstanding rigorous operational conditions. The HF-16's minimum bend radius is remarkably small at only 1.8 inches (45.00 mm), providing exceptional flexibility for tight configurations in machinery. Constructed from seamless, black oil- and heat-resistant synthetic rubber, the HF-16’s tube is designed to ensure safe and efficient fluid transport under various thermal conditions, ranging from -40°C to +100°C (-40°F to +212°F). The hose's reinforcement includes textile braiding with spiral wire to prevent collapsing under vacuum or during use, enhancing its structural integrity. Furthermore, its cover is made from black synthetic rubber that is also oil- and heat-resistant and approved by MSHA for quality assurance. Weighing only 0.50 lbs per foot and available in lengths ranging from a minimum of 12 inches to a maximum of 1200 inches, the HF-16 offers considerable versatility in installation options. It utilizes EN series couplings for secure connections, ensuring reliable integration into existing hydraulic systems. This model's design meets or exceeds the rigorous requirements set by SAE 100R4 standards, affirming its suitability for suction lines or low-pressure return lines in hydraulic applications.
HF 100R4 Suction / Return Hose
Meets or exceeds the requirements of SAE 100R4.
Tube: Seamless, black, oil and heat resistant synthetic rubber
Reinforcement: Textile braided with spiral wire to prevent collapsing
Cover: Black synthetic oil and heat-resistant rubber, MSHA approved
Temperature: -40°C to 100° (-40°F to +212°F)
Packaging: 100’ Coils
Application: Petroleum and water based hydraulic fluids in suction lines or in low pressure return lines.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | VACUUM HG | ONE PIECE | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | (in) | COUPLINGS | |
| HF-16 | 1 | 1.38 | 35.00 | 250 | 1000 | 1.8 | 45.00 | 0.50 | 28 | coupling_HF |
