FLEXTRAL
GH-12
- FLEXTRAL
- Material:GH-12
- Summary:GH
Due to extremely high demand, please call 800-374-7411 for availability
GH 1SN High-Temp. One Wire Braid Hose
Meets or exceeds the requirements of SAE 100R1AT and EN853 DIN 20022 1SN-ISO 1436 Type 1.
Tube: Specially formulated CSM compound
Reinforcement: One braid of high-tensile steel wire
Cover: Blue, perforated, oil, abrasion and weather resistant synthetic rubber, MSHA approved
Temperature: -40°F to 302°F, except for air 250°F; max -40°C to 150°C, except for air 121°C max; 200°F or 100°C max for water-based solutions.
Packaging: 3⁄16” - 1” Reels, 11⁄4” - 2” Coils
Application: High-temperature, medium pressure hydraulic and fuel applications. Suitable for passage of mineral and vegetable oils, *water-based solutions, air and inert gases. SAE J1942/1 USCG - HF Type B accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE | ||
|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | |
| GH-12 | 3⁄4 | 1.09 | 27.70 | 1500 | 6000 | 9.5 | 240.00 | 0.42 | coupling_GH |
