The Flextral FX-16 (FX-16) is a high-performance hydraulic hose designed for a variety of demanding applications. It features a seamless, black, oil and heat-resistant synthetic rubber tube, reinforced with one braid of synthetic yarn and one braid of steel wire. The cover is made from black, impregnated textile braid that is oil and mildew resistant and approved by MSHA. This hose meets or exceeds the performance requirements of SAE 100R5 and D.O.T. FMVSS 106. With an internal diameter of 78 inches and an outer diameter of 31.40 mm, the FX-16 ensures efficient fluid transfer under pressures up to 800 psi maximum working pressure, with a minimum burst pressure of 3200 psi. It can handle temperatures ranging from -40°C to +135°C, making it suitable for high-temperature hydraulic applications involving diesel fuel and lubricating oils. The Flextral FX-16 offers flexibility with minimum bend radius specifications at 187 mm, ensuring ease of installation in tight spaces. Available in lengths ranging from a minimum of 12 inches to a maximum of 1200 inches, it can be used in various configurations. The hose is typically packaged in coils for sizes 13/8 inches and higher, while smaller sizes are available on reels. This hose is also compliant with SAE J1942/1 USCG H standards making it ideal for marine applications where US Coast Guard approval is required. Its robust construction and compliance with critical industry standards make the FX-16 suitable for a wide range of industrial applications where durability and reliability are paramount.
The Flextral FX-16 (FX-16) is a high-performance hydraulic hose designed for a variety of demanding applications. It features a seamless, black, oil and heat-resistant synthetic rubber tube, reinforced with one braid of synthetic yarn and one braid of steel wire. The cover is made from black, impregnated textile braid that is oil and mildew resistant and approved by MSHA. This hose meets or exceeds the performance requirements of SAE 100R5 and D.O.T. FMVSS 106. With an internal diameter of 78 inches and an outer diameter of 31.40 mm, the FX-16 ensures efficient fluid transfer under pressures up to 800 psi maximum working pressure, with a minimum burst pressure of 3200 psi. It can handle temperatures ranging from -40°C to +135°C, making it suitable for high-temperature hydraulic applications involving diesel fuel and lubricating oils. The Flextral FX-16 offers flexibility with minimum bend radius specifications at 187 mm, ensuring ease of installation in tight spaces. Available in lengths ranging from a minimum of 12 inches to a maximum of 1200 inches, it can be used in various configurations. The hose is typically packaged in coils for sizes 13/8 inches and higher, while smaller sizes are available on reels. This hose is also compliant with SAE J1942/1 USCG H standards making it ideal for marine applications where US Coast Guard approval is required. Its robust construction and compliance with critical industry standards make the FX-16 suitable for a wide range of industrial applications where durability and reliability are paramount.
FX 100R5 Textile Cover
Meets or exceeds performance requirements of SAE 100R5 and D.O.T. FMVSS 106.
Tube: Seamless, black, oil, and heat resistant synthetic rubber
Reinforcement: One braid of synthetic yarn and one braid of steel wire
Cover: Black, impregnated textile braid, oil and mildew resistent, MSHA approved
Temperature: 3⁄16” - 11⁄8” reels, 13⁄8” and higher in coils
Packaging: Coils
Application: Used for high-temperature, hydraulic applications, diesel fuel and lubricating oils. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE | REUSABLE | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | COUPLINGS | |
| FX-16 | 7⁄8 | 1.24 | 31.40 | 800 | 3200 | 7.4 | 187.00 | 0.47 | coupling_FX | coupling_reusable |
