The Flextral FX-04 (FX-04) is a highly versatile hydraulic hose designed for high-temperature applications. It is constructed to meet or exceed the performance requirements of SAE 100R5 and D.O.T. FMVSS 106 standards, ensuring reliability and safety. The hose features a seamless, black, oil and heat-resistant synthetic rubber tube with a reinforcement layer consisting of one braid of synthetic yarn and one braid of steel wire. This construction enhances the hose's strength and durability, allowing it to withstand a maximum working pressure of 3000 psi and a minimum burst pressure of 12000 psi. The outer cover of the FX-04 is made from black, impregnated textile braid that is oil and mildew resistant as well as MSHA approved, which adds to its robustness in harsh environments. With an internal diameter of approximately 3/16 inches and an outer diameter of 13.20 mm, this hose maintains a minimal bend radius of 76 mm, making it flexible enough for tight routing scenarios in hydraulic systems. Suitable for use with high-temperature fluids, diesel fuel, and lubricating oils, the FX-04 finds applications primarily in hydraulic systems where temperature extremes are encountered. Its design also includes compatibility with SAE J1942/1 USCG H accepted standards for marine applications. Available in lengths ranging from 12 inches to 1200 inches, it offers ample flexibility for various installation needs. The Flextral FX-04 is offered typically on reels for sizes up to 1⅛ inches and in coils for larger sizes, facilitating easy handling and storage.
The Flextral FX-04 (FX-04) is a highly versatile hydraulic hose designed for high-temperature applications. It is constructed to meet or exceed the performance requirements of SAE 100R5 and D.O.T. FMVSS 106 standards, ensuring reliability and safety. The hose features a seamless, black, oil and heat-resistant synthetic rubber tube with a reinforcement layer consisting of one braid of synthetic yarn and one braid of steel wire. This construction enhances the hose's strength and durability, allowing it to withstand a maximum working pressure of 3000 psi and a minimum burst pressure of 12000 psi. The outer cover of the FX-04 is made from black, impregnated textile braid that is oil and mildew resistant as well as MSHA approved, which adds to its robustness in harsh environments. With an internal diameter of approximately 3/16 inches and an outer diameter of 13.20 mm, this hose maintains a minimal bend radius of 76 mm, making it flexible enough for tight routing scenarios in hydraulic systems. Suitable for use with high-temperature fluids, diesel fuel, and lubricating oils, the FX-04 finds applications primarily in hydraulic systems where temperature extremes are encountered. Its design also includes compatibility with SAE J1942/1 USCG H accepted standards for marine applications. Available in lengths ranging from 12 inches to 1200 inches, it offers ample flexibility for various installation needs. The Flextral FX-04 is offered typically on reels for sizes up to 1⅛ inches and in coils for larger sizes, facilitating easy handling and storage.
FX 100R5 Textile Cover
Meets or exceeds performance requirements of SAE 100R5 and D.O.T. FMVSS 106.
Tube: Seamless, black, oil, and heat resistant synthetic rubber
Reinforcement: One braid of synthetic yarn and one braid of steel wire
Cover: Black, impregnated textile braid, oil and mildew resistent, MSHA approved
Temperature: 3⁄16” - 11⁄8” reels, 13⁄8” and higher in coils
Packaging: Coils
Application: Used for high-temperature, hydraulic applications, diesel fuel and lubricating oils. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE | REUSABLE | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | COUPLINGS | |
| FX-04 | 3⁄16 | 0.52 | 13.20 | 3000 | 12000 | 3 | 76.00 | 0.15 | coupling_FX | coupling_reusable |
