FLEXTRAL
FH-10

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Flextral directly.***
The Flextral FH-10 (FH-10) is designed to meet the rigorous requirements of SAE 100R5 and D.O.T. FMVSS 106 standards, ensuring high performance in a range of demanding applications. This hose features a seamless, black, oil and heat-resistant synthetic rubber tube, reinforced with one braid of synthetic yarn and one braid of steel wire. The cover is a blue, impregnated textile braid that is oil and mildew resistant and approved by MSHA. With an internal diameter of 12 inches and an outer diameter of 23.40 mm, the FH-10 maintains a maximum working pressure of 1750 psi and can withstand up to 7000 psi in burst pressure. Its flexibility is evidenced by a minimum bend radius of 140 mm. The hose's length ranges from a minimum of 12 inches to a maximum of 1200 inches, catering to extensive hydraulic system needs. The FH-10 operates efficiently within a temperature range from -40°C to +150°C with petroleum-based fluids, -40°C to +107°C with water-oil emulsions or water-glycol solutions, and -40°C to +42°C with phosphate ester fluids. It is particularly suited for high-temperature hydraulic applications and lubricating oils. This model uses F5R series couplings, enhancing its utility in various hydraulic setups. The packaging varies from reels for smaller diameters to coils for sizes 13/8 inches and higher, ensuring optimal handling during transport and storage. Additionally, the FH-10 is accepted for use under SAE J1942/1 USCG H specifications, further attesting to its suitability for high-stakes environments where reliability is paramount.
