***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Flextral directly.***
The Flextral CX-32 (CX-32) is a robust hydraulic hose designed for extreme high-pressure applications. This premium product is part of the CX series and features a 2-inch internal diameter, making it suitable for a wide range of demanding hydraulic systems. The hose boasts an impressive maximum working pressure of 6000 psi and a minimum burst pressure of 24000 psi, ensuring reliability and safety under tough conditions. With a minimum bend radius of 23.5 inches (600 mm), it offers flexibility in installation and use. Constructed with a nitrile tube and reinforced by six spiral layers of high-tensile steel wire for sizes ranging from 1¼ to 2 inches, the CX-32 is engineered to handle severe pressures. The outer cover is made from black synthetic rubber that is resistant to oil, abrasion, and weather conditions, complemented by an EPDM layer that enhances its durability against environmental factors. This design specification ensures the hose performs optimally between -40°C to +121°C (-40°F to +250°F), catering to a broad spectrum of temperature requirements. The CX-32 can be utilized in hydraulic systems that operate with petroleum or water-glycol based fluids, as well as in applications involving fuel, diesel fuel, and lubricating oils. It is also compatible with biodegradable hydraulic oils, promoting environmentally responsible usage. Available in lengths ranging from 12 inches to 1200 inches and weighing approximately 5.00 lbs per foot, this hose can be tailored to specific requirements using VS series couplings with C skive type settings. Packaged in coils for convenience and ease of handling, the Flextral CX-32 offers an efficient solution for high-capacity fluid dynamics applications within various hydraulic setups.
The Flextral CX-32 (CX-32) is a robust hydraulic hose designed for extreme high-pressure applications. This premium product is part of the CX series and features a 2-inch internal diameter, making it suitable for a wide range of demanding hydraulic systems. The hose boasts an impressive maximum working pressure of 6000 psi and a minimum burst pressure of 24000 psi, ensuring reliability and safety under tough conditions. With a minimum bend radius of 23.5 inches (600 mm), it offers flexibility in installation and use. Constructed with a nitrile tube and reinforced by six spiral layers of high-tensile steel wire for sizes ranging from 1¼ to 2 inches, the CX-32 is engineered to handle severe pressures. The outer cover is made from black synthetic rubber that is resistant to oil, abrasion, and weather conditions, complemented by an EPDM layer that enhances its durability against environmental factors. This design specification ensures the hose performs optimally between -40°C to +121°C (-40°F to +250°F), catering to a broad spectrum of temperature requirements. The CX-32 can be utilized in hydraulic systems that operate with petroleum or water-glycol based fluids, as well as in applications involving fuel, diesel fuel, and lubricating oils. It is also compatible with biodegradable hydraulic oils, promoting environmentally responsible usage. Available in lengths ranging from 12 inches to 1200 inches and weighing approximately 5.00 lbs per foot, this hose can be tailored to specific requirements using VS series couplings with C skive type settings. Packaged in coils for convenience and ease of handling, the Flextral CX-32 offers an efficient solution for high-capacity fluid dynamics applications within various hydraulic setups.
CX Premium Six Spiral Wire Hose
Meets or exceeds the requirements of SAE 100R15.
Tube: Nitrile
Reinforcement: Four spiral layers of high-tensile steel wire 1⁄2” thru 1”. Six spiral layers of high-tensile steel wire 11⁄4” thru 2”
Cover: Black, oil, abrasion and weather resistant synthetic rubber, EPDM
Temperature: -40°C to +121°C (-40°F to +250°F)
Packaging: Coils
Application: Hydraulic systems with petroleum or water/glycol based fluids, fuel, diesel fuel, and lubricating oils. Suitable for use with biodegradable hydraulic oils.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE Non-Skive | ONE PIECE Skive | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | COUPLINGS | |
| CX-32 | 2 | 2.95 | 75.00 | 6000 | 24000 | 23.5 | 600.00 | 5.00 | C | |
