CX Premium Six Spiral Wire Hose
Meets or exceeds the requirements of SAE 100R15.
Tube: Nitrile
Reinforcement: Four spiral layers of high-tensile steel wire 1⁄2” thru 1”. Six spiral layers of high-tensile steel wire 11⁄4” thru 2”
Cover: Black, oil, abrasion and weather resistant synthetic rubber, EPDM
Temperature: -40°C to +121°C (-40°F to +250°F)
Packaging: Coils
Application: Hydraulic systems with petroleum or water/glycol based fluids, fuel, diesel fuel, and lubricating oils. Suitable for use with biodegradable hydraulic oils.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE Non-Skive | ONE PIECE Skive | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | COUPLINGS | |
| CX-12 | 3⁄4 | 1.2 | 30.70 | 6000 | 24000 | 11 | 280.00 | 1.09 | V | |
