HYDRAFORCE
5471009


$278.25 USD
  • HYDRAFORCE
  • Material:5471009
  • Model:HP16-21A-6B-N HAND PUMP
  • Summary:HAND PUMP

Quantity in stock: 0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5471009 (5471009) is a versatile and robust hand pump designed for general purpose hydraulic oil applications. Known as the HP1621X, this model features a unique push or pull to pressurize mechanism, enhancing its usability in various situations. It incorporates two built-in checks that ensure reliable operation by preventing backflow and maintaining system integrity. As a screw-in, cartridge type hand pump, it offers ease of installation and maintenance, making it an ideal choice for systems requiring manual hydraulic control. The HP1621X's design allows the hand pump beam to rotate around the vertical axis, providing 360-degree handle positioning. This flexibility is particularly beneficial in confined or awkward spaces where handle movement might be restricted. Additionally, this hand pump can serve as an emergency backup device during electrical power failures, highlighting its utility in critical applications where hydraulic power is essential for continued operation. Overall, the Hydraforce 5471009 hand pump is engineered to meet the needs of users requiring a reliable, manually operated hydraulic system component with flexible handling and emergency operational capabilities.

Description The HP16-21X is a push or pull to pressurize hand pump with two built in checks. It is a screw in, cartridge type hand pump for use with general purpose hydraulic oils. The hand pump beam rotates around the vertical axis for 360° handle positioning. The hand pump CAN be used as an emergency device at electrical power failures.

Displacement: 21.3 ml (1.3 in³)
Per stroke

Unit weight: 1.27 kg (2.8 lb)

Internal wetted surface area: 214 cm² (33.2 in²)

RatingsPressure Ratings
Pressure rating: 345 bar (5000 psi)
At port 2

Suction pressure: 193 mm-Hg (7.6 in-Hg)
Less than atmospheric pressure

Flow Ratings
Maximum internal leakage: 3 drops/min
From port 2 to the inside of the pump. Maximum at 207 bar (300
psi)

Temperature Ratings
Operating fluid temperature: -40 to 100 °C (-40 to 212 °F)
With buna N seals
-26 to 204 °C (-15 to 400 °F)
With fluorocarbon seals

Storage temperature: -40 to 70 °C (-40 to 160 °F)

Ambient temperature: -40 to 90 °C (-40 to 194 °F)

Other Ratings
Corrosion protection: 960 hr salt spray per ASTM b117 (ghp16-21x)
Operating ParametersFluids: Mineral based or synthetic hydraulic fluid with lubricating
properties

Fluid viscosity range: 7.4 to 420 cSt

Maximum operating contamination level: 20/18/14 per ISO 4406
Performancehttps://www.hydraforce.com/globalassets/product-images/hp16-21_chrt2022-02-24.gif

Installation SpecificationsCavity: VC16-2
16-size-2-way Cavities
Maximum allowable torque: 305 N-m (225 ft-lb)

Cartridge installation torque: 62.3 to 73.2 N-m (46 to 54 ft-lb)

Orientation restriction: None
Order CodePOSITION CODE DESCRIPTION HP16-21-H-J H Line Body H 0 No Body H 12T Aluminum SAE 12 H 16T Aluminum SAE 16 H 12TD Ductile Iron SAE 12 H 6B Aluminum BSPP 3/4" (6) H 8B Aluminum BSPP 1" (8) H 8BD Ductile Iron BSPP 1" (8) J Seal J N Buna-N J V Fluorocarbon J P Polyurethane J U PPDI Urethane
https://www.hydraforce.com/globalassets/product-images/hp16-21_dim2022-02-24.gif


Accessories: 40 cm (16 in) long handle with plastic grip (p/n: 6502340)

Seal kit: SK16-2N-T
Buna N
SK16-2V-T
Fluorocarbon
Seal kit installation instructions
Housings:
Available
16-2w valve bodies
