HYDRAFORCE
5436927
$201.25 USD
- HYDRAFORCE
- Material:5436927
- Model:FD50-45-8DD-N-66 FLOW DIVIDER
- Summary:FLOW DIVIDER/COMBINER VALVE
Quantity in stock: 35
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce FD50-45-8DD-N-66 (5436927) is a high-performance screw-in cartridge, spool type flow divider/combiner valve designed for advanced hydraulic systems. This valve excels in providing pressure-compensated proportional division of inlet flow or combining of two return flows, maintaining stability and efficiency regardless of system pressure variations. It is particularly effective in applications requiring precise flow management to ensure synchronized operation in both dividing and combining modes. Constructed with hardened parts, the FD50-45-8DD-N-66 ensures durability and a long service life even under rigorous conditions. Its design features include a quiet, modulated response and a wide operating flow range from 19 to 57 liters per minute (5.0 to 15.0 gallons per minute). The valve achieves flow accuracy within ±15% of maximum inlet flow, with a synchronizing flow approximately 10% of this value, ensuring reliable performance in varied applications. This model is suited for use with mineral-based or synthetic hydraulic fluids that possess lubricating properties, enhancing its versatility across different hydraulic systems. It also incorporates a floating cage for high installation torque and utilizes an industry-common cavity (VC104), facilitating ease of installation and compatibility with standard setups. Additional features like the availability of seal kits (SK104NMMM) and housings for 104W valve bodies further extend its applicability and ease of maintenance, making it an essential component for efficient hydraulic operations where precise fluid control is critical. With a pressure rating up to 345 bar (5000 psi) and a pressure drop limited to 20.5 bar (300 psi) at maximum inlet flow, the FD50-45-8DD-N-66 stands out as a robust solution for demanding hydraulic tasks.
The Hydraforce FD50-45-8DD-N-66 (5436927) is a high-performance screw-in cartridge, spool type flow divider/combiner valve designed for advanced hydraulic systems. This valve excels in providing pressure-compensated proportional division of inlet flow or combining of two return flows, maintaining stability and efficiency regardless of system pressure variations. It is particularly effective in applications requiring precise flow management to ensure synchronized operation in both dividing and combining modes. Constructed with hardened parts, the FD50-45-8DD-N-66 ensures durability and a long service life even under rigorous conditions. Its design features include a quiet, modulated response and a wide operating flow range from 19 to 57 liters per minute (5.0 to 15.0 gallons per minute). The valve achieves flow accuracy within ±15% of maximum inlet flow, with a synchronizing flow approximately 10% of this value, ensuring reliable performance in varied applications. This model is suited for use with mineral-based or synthetic hydraulic fluids that possess lubricating properties, enhancing its versatility across different hydraulic systems. It also incorporates a floating cage for high installation torque and utilizes an industry-common cavity (VC104), facilitating ease of installation and compatibility with standard setups. Additional features like the availability of seal kits (SK104NMMM) and housings for 104W valve bodies further extend its applicability and ease of maintenance, making it an essential component for efficient hydraulic operations where precise fluid control is critical. With a pressure rating up to 345 bar (5000 psi) and a pressure drop limited to 20.5 bar (300 psi) at maximum inlet flow, the FD50-45-8DD-N-66 stands out as a robust solution for demanding hydraulic tasks.
Unit weight:
0.49 kg (1.07 lb)
| Ratings | Pressure Ratings Pressure rating: 345 bar (5000 psi) Pressure drop: 20.5 bar (300 psi) At maximum inlet flow Flow Ratings Inlet flow rating: 19 to 57 lpm (5.0 to 15.0 gpm) Synchronizing flow: Approximately 10% of maximum inlet flow Flow accuracy: 15 % Of inlet flow (maximum) |
| Performance |  |
| Installation Specifications | Cavity:
VC10-4 10-size-4-way Cavities |
| Order Code | POSITION CODE DESCRIPTION FD50-45-H-J-N H Line Body H 0 No Body H 6T Aluminum SAE 6 H 6TD Ductile Iron SAE 6 J Seal J N Buna-N J V Fluorocarbon J P Polyurethane N Flow Dividing/Combining N 22 50/50 Rated at 4.0-19.0 lpm (1.0-5.0 gpm) N 33 50/50 Rated at 5.5-26.5 lpm (1.5-7.0 gpm) N 44 50/50 Rated at 9.5-38.0 lpm (2.5-10.0 gpm) N 55 50/50 Rated at 11.5-41.5 lpm (3.0-11.0 gpm) N 66 50/50 Rated at 15.0-45.0 lpm (4.0-12.0 gpm) N 88 50/50 Rated at 19.0-57.0 lpm (5.0-15.0 gpm) |
Seal kit:
SK10-4N-MMM
Seal kit installation instructions
Housings:
Available
10-4w valve bodies
